MOTOR COMPATIBILITY
For maximum motor life without using a line filter, the use of an inverter duty motor is recommended.

Electrical Noise Emissions and filtering: Electrical noise emissions (EMI) are highly dependent on load and environment. For many applications no additional filtering is required to meet EN55011/FCC class A emissions standards. For applications requiring additional filtering CRI recommends the following filters or equivalents:

EN55011/FCC class A:
150KHz – 30mHz EN55011/FCC class B:
10KHz-30mHz Filter Concepts: LE series
www.filterconcepts.com Filter Concepts: LX series
www.filterconcepts.com Corcom S series,
www.cor.com Corcom Q series,
www.cor.com

Controlling multiple motors: Multiple motors wired in parallel can be controlled from one Stratus II as long as maximum peak (startup) currents do not exceed 10 Amps.

Control Accuracy and Hysteresis: Control signal accuracy is as follows:

Voltage ± 0.38VDC
Current ± 0.4mA
Temperature ± 1.5Cº

In alarm conditions, loss of signal and ON/OFF feature, hysteresis is added to eliminate cycling. Hysteresis is as follows:

Voltage ± 2%
Current ± 1.5%
Temperature 1-2Cº

RoHS compliance: Stratus II is RoHS (6/6) compliant
